Mesa Installation Guide

Welcome to Mesa! We are excited to have you as a customer. Please call or email us anytime if we can support your installation:
mesasupport@google.com
(855) 572-4646

A woman presses a Mesa sensor up against the wall
Sensor icon

Step 1: Cloud Connector

Sends sensor data to the cloud

Insert one end of the ethernet cable into the Cloud Connector and the other into the power adapter’s port labeled “OUT.” Plug in a place with good cell reception and within 75 feet of where you’ll place the temperature, humidity, motion, leak, air quality, comfort, and proximity sensors. Use the mounting bracket or adhesives to secure to the wall.

That's it! Check the display for data connection (white cloud icon) and its strength (up to four dots).

Wifi icon

Step 1.1: Wi-Fi Router

Provides secure data connectivity for Mesa devices

Unfold its three antennas. Plug in a place with good cell reception and within 60 feet of the thermostat. Use the mounting bracket or adhesives to secure to the wall.

That's it! The LED indicators show power ⏻, wifi, and cell signal 📶.

Smart plug icon

Step 2: Smart Plugs

Measure electric usage and turn devices on/off

Plug into an outlet where you’d like to measure electric usage and be able to turn devices on/off (e.g. space heaters or televisions).

The solid blue light means a connection is established. If not on, press the button on the right.

Thermostat icon

Step 3: Temperature & Humidity Sensors

Measure ambient temperatures and humidities

Stick on room-temperature spots between 4 and 6 feet off the ground. Avoid metal surfaces, air vents, walls exposed to sunlight, and heating/cooling sources.

Find instructions for installing temperature sensors near air supply grilles and radiators here.


Step 4: Window/Door Proximity Sensors

Detect open windows and doors

Open a window or door and stick a sensor to any part of the door/window frame where the sensor will be visible when opened, but not visible when closed. If dusty, use the included alcohol wipes to clean the frame, then let the surface dry. Avoid metal surfaces.

Check mark icon

Step 5: Comfort Buttons

Allow people to give real time feedback

Place where people can see and easily reach. That's it!

Temperature sensor icon

Step 6: Thermostat

Controls temperature, connects to the motion sensors and measures temperature, humidity, and occupancy

Not using Mesa for HVAC controls? Here is the installation guide for the thermostat section.

If you’re using Mesa for HVAC controls, first ensure that the old thermostat is working properly. ⚠️ Use the circuit breaker box to power off Heating, Ventilation, and Air Conditioning (HVAC) systems. Remove the old thermostat cover. 🛑 STOP if you see warning indicators about “HIGH VOLTAGE,” 110 VAC, 120 VAC, 240 VAC, or L1 L2 markings. Check to ensure you have a C wire connected to the old thermostat. If not, contact support.

Take a picture of the existing wiring. One at a time, disconnect and label the wires from your old thermostat using the labels provided. Remove the old thermostat back plate, and place the new one (pull wires through, and mount using screws or adhesive). Insert your R wires. If you have more than one R wire: R or RC ➔ RC and RH ➔ RH. If not, insert single wire: R, RC, or RH ➔ RC. Insert your remaining wires into the side (not the front) of their corresponding terminal blocks. Push excess wire back into the wall so that the thermostat will easily snap into place. Gently press your smart thermostat into the backplate until it clicks into place. Turn your HVAC systems on.

That's it! Use the thermostat screen to check that it’s connected to your Wi-Fi by pressing MAIN MENU (three lines at the bottom of the screen) > SETTINGS > Wi-Fi. It should say "Connected to <network name>."

Dashboard icon

Step 7: Motion Sensors

Detect movement

If you have wall motion sensors, remove protective film from the front of the motion sensor. Place the sensors on surfaces, like a desk (using the cone stands) or stick them to the wall (with the adhesive) about five feet off the ground. They should have an unobstructed wide view of the area. Avoid hot/cold surfaces.

That's it! On the thermostat, go to MAIN MENU > SENSORS to check that the motion sensor icon (motion sensor icon) is there. If not there, wait five minutes and try again.

If you have ceiling motion sensors, clean the surface with an alcohol pad (included). Remove protective film from the backplate before sticking; press onto the clean surface for 30 seconds and allow the adhesive to set for 24 hours. Lock the sensor in place on the backplate by turning it clockwise onto the bracket; use a phillips head screwdriver to tighten the safety screw in place. That’s it!

Step 8: Leak Detectors

Detect the presence of water

Stick it in a location where water from potential leaks would collect. Clean the surface with an alcohol pad (included). The optional leak detection extender (included) can be added to any device where leak detection range is desired. The device will sense water on any part of the tape extension. That’s it!

Step 9: Air Quality Monitors

Measure CO2

Stick it on a wall 4’-6’ off the ground. Locate device at least 3’ from doors, windows, air vents, and heating/cooling sources. That’s It!

All Steps: How to Install Mesa in 6 Minutes
